Quick Details

  • Place of Origin: Fujian, China (Mainland)
  • Brand Name: DAZHEN
  • Model Number: DZ-K20AA
  • Usage: Home Appliance, Recorder/CD/DVD motor
  • Certification: ROHS, Halogen Free, ISO9001,ISO14000
  • Type: DC Mini Motor
  • Torque: 0.2N.m
  • Construction: Permanent Magnet
  • Commutation: Brush
  • Protect Feature: Totally Enclosed
  • Speed(RPM): High Speed
  • Continuous Current(A): Low Current
  • Output Power: 0.06W
  • Voltage(V): 3.0V
  • Efficiency: IE 2

Packaging & Delivery

Packaging Details Packing:
1,000pcs/carton
Volume: 0.019cbm
N.W.: 2.6kg
G.W.: 3.0kg
Delivery Time 20 Days

Micro DC Motor for CD

DC Brushed Mini Motor DZ-K20AA:
Motor Shape:Flat
Outline Dimension(DxLxH):8.0mmx14.5mmx6.0mm



Typical applications:
1) Notebook PC
2) Apply to CD / DVD-ROM drive
3) Other industrial equipment



 Specifications:

Technical Characteristic(only for reference,we are capable of meeting the sourcing needs of diverse buyer).

Model

Voltage

No Load

On Load

At Stall

Operating

Range

Nominal

Voltage

Speed

Current

Speed

Current

Torque

Output

Torque

Current

r/min

A

r/min

A

g.cm

mN.m

W

g.cm

mN.m

A

DZ-K20AA

3.0MAX

1.5V

11500

0.065

8100

0.14

0.74

0.07

0.06

2

0.2

0.32

Unit Conversion: 1g.cm≈0.098mN.m≈0.014oz.in  1mm=0.039in  1g=0.035oz





.
